AC High-Low Power Unit

AC 3000 SERIES

AC High-Low Power Unit

Description

For applications that require high speeds at low pressure and low speeds at high pressure.

Specifications

Motor
1 PHASE (110V-220V AC) OR 3 PHASE (230V-440V AC), 1 TO 3 HP (800W – 2.4KW)
Pressure
500 – 3000 PSI (35 BAR – 205 BAR), Typical pressure is 2000 PSI (135 BAR)
Pump
0.5 GPM TO 3.0 GPM (1.9 LPM – 11 LPM) Based on Specification
Reservoir
Steel or Plastic, 1.5 QT (1.42 LTR) to 5 Gallon (18.93 LTR)
Control
Not Offered

Technical Application

  • Trash Compactor
  • Tensile Strength Testing Equipment
  • Hose Crimper Equipment
  • Tire Changer Equipment
AC Hi Low
AC 3000 Series AC High-Low Power Unit
Circuit
For more information on our hydraulic power units, please contact one of our specialists by phone, (949) 752-8818 or by email at sales@ktihydraulicsinc.com.
